Pelonis Technologies' innovative Micro Fans are uniquely engineered for high quality, value and performance to meet the needs of today's demanding applications.
The Need For Miniature Cooling
Today's industries for cooling products require devices that are increasingly smaller, lightweight, have low power consumption, and reduce heat generation.
Micro Fans are ideal thermal cooling solutions for applications that have limited space with restricted power budgets. They manage heat generation effectively, are energy efficient, and have a long operating life.
Micro Fans Quick Reference Chart
Model | V | Bearing | Range (V) | mA | RPM | CFM | m3/min | mmAq | inH2O | dba | |
---|---|---|---|---|---|---|---|---|---|---|---|
AGA135 | 3.0 3.3 |
Axially Grooved | 2.5~3.6 | 32 34 |
15000 16000 |
0.15 0.16 |
0.004 0.005 |
1.70 1.98 |
0.067 0.078 |
15.2 15.7 |
|
AGA154 | 3.3 5.0 |
Axially Grooved | 2.8~3.6 4.5~5.5 |
30 42 |
10000 16000 |
0.30 0.40 |
0.009 0.011 |
1.5 2.80 |
0.059 0.110 |
25.0 < 35.0 |
|
AGA154U | 2.4 | Axially Grooved | 2.4~3.3 | 11 | 7500 | 0.12 | 0.003 | 0.69 | 0.027 | 14.6 | |
AGA178 | 3.3 5.0 |
Axially Grooved | 2.8~5.5 | 55 85 |
12000 16000 |
0.67 0.95 |
0.019 0.027 |
3.42 6.86 |
0.134 0.270 |
12.0 18.0 |
|
AGA184 | 3.3 5.0 |
Axially Grooved | 2.8~3.6 4.5~5.5 |
32 45 |
8500 13000 |
0.65 0.90 |
0.018 0.026 |
1.95 3.50 |
0.077 0.138 |
25.0 < 35.0 |
|
AGA308 | 3.3 5.0 |
Axially Grooved | 2.8~5.5 | 45 65 |
4500 6200 |
1.89 2.60 |
0.054 0.074 |
1.38 2.62 |
0.054 0.103 |
17.0 22.0 |
Axial Air-Gap Cooling
Traditional blowers include silicon steel motors with radial air-gaps. Miniaturization is difficult, operation is inefficient, and power loss is greater at higher temperatures.
By using Axial Air-Gap Technology, Micro Fans are smaller and more energy efficient than traditional blowers and have almost no power loss at higher temperatures.
Micro Fans can be used in a variety of applications, including:
- Portable medical devices
- Portable computers and electronics
- LED lighting
- Smartbooks and tablets
- Portable HDD
- IP cameras
- High-speed memory modules
- CCTV security surveillance systems
- Pocket projectors
- Micro fuel cells
- GPS devices
- Portable gas/particle detectors
- Portable plasma generators
- Portable air-quality monitoring devices
- Ventilation and defrosting
- Mask/Helmet/Glass ventilation
- Solar and wind energy devices
Micro Fans are ideal alternatives to traditional fans and can be customized to satisfy a variety of applications that require an effective minature cooling station.
